To comprehensively monitor IAQ and ozone levels from printers or air purifiers, ensuring a healthy and productive indoor environment.
For real-time monitoring of ozone concentrations generated by equipment to protect employee health and safety.
To monitor air quality and ozone levels in disinfection areas or from medical equipment, safeguarding patient and staff well-being.
To protect sensitive components and materials from potential oxidation or damage caused by elevated ozone levels.
| Measurement Content | Range | Resolution | Response Time |
|---|---|---|---|
| IAQ | 0-10ppm | 0.01ppm | <3s(T90<15s) |
| O₃ | 0-5ppm | 0.01ppm | <3s(T90<15s) |
| Temperature | -25～80℃ | ±0.2℃（at 25℃) | Real-time |
| Humidity | 0～99.9%RH | ±2%RH（at 25℃) | Real-time |
| Table 2 - Technical Specifications | |
| Measurement Content | IAQ, O₃, Temperature, Humidity, Dew Point |
| Power Supply | DC12～48V, POE power supply |
| Communication Protocol | Modbus TCP, UDP, SNMP（V1.V2), MQTT |
| Communication Interface | RJ45 |
| Interface | 2 channels DI input, 1 channel DO output, 1 channel RS485, 1 channel DC12V output |
| Alarm | Light, sound, email alarm, protocol alerts |
| Screen Display | 3.5 inch TFT color screen |
| Data Storage | 100,000 records |
| Installation | Screw fixation, Magnetic |
| Dimensions | 100*135*35mm |
